RC926 Swiss Type CNC Lathe

2 Spindle Swiss Type Cnc Automatic Lathe Machine RC926 High Precision 5 Axis Cnc Lathe For Metal Cutting

Inquire Now

None

Share

CONTACT US

Dalian R&C Machinery Co., Ltd.

High Precision RC926 2 Spindle 5 Axis Swiss Type Cnc Automatic Lathe Machine Cnc Lathe

The main structural features:

1.10,000rm maximum spindle rotation speed: ultra-high spindle and back spindle rotation speed, which can provide the best processing conditions when slender materials and small diameter tools are used. 2.250mm single clamping processing length: super long single clamping processing length, the workpiece that needs to be changed to be processed before can be completed in one clamping, which shortens the processing time. 3.Ø26mm Optional maximum clamping device: the diameter of the spindle through hole is Ø26mm, and it can be equipped with a Ø26 clamping device for processing large materials. 4.Both the spindle and the back spindle adopt high-precision built-in electric spindles. 5.The dual-channel design significantly improves production efficiency. Equipped with a special tool holder for the back, it can shorten the processing time through the independent processing of the front/back.

Project

Model

RC926

Processing parameters

Max processing diameter

Φ26mm



Max processing length

190mm



Max axial drilling diameter

Φ10mm



Max axial tapping size

M8



Max spindle speed

10000rpm



Max radial drilling diameter

Φ7mm



Max radial tapping size

M6



Max speed of radial power head

ER11:10000/ER16:8000



Rated speed of radial power head

ER11:8000/ER16:6000



Max extraction length of workpiece

100mm

Tool sizes

Number of tools installed

6



Tool (turning tool)

12X12



Sleeve

Φ25.0 X 4T

Chuck guide bush

Spindle collet

TSUGAMI B0265CCR



Power head chuck

ER11、ER16



Bushing

TSUGAMI BS-20#-B

Feed speed

Z1/Z2/X2/Y axis feed rate

30m/min



X1

20m/min

Motor

Spindle drive power

2.5/3.7KW



Power head drive power

1KW



For cutting oil

0.4KW



For spindle cooling

0.075KW



For lubricating oil

0.01KW

Others

Spindle center height

1060mm



Air pressure flow

0.7mpa 0.5m³/min



Main circuit breaker capacity

40A



Input power

9.3KW



Weight

2600



Dimensions

2250X1200X1850mm
