MVL1165 Large Machining Center
High Quality 3 Axis Machine Centre MVL1165 Large Cnc Vertical Machining Center
CNC vertical machine center vmc cnc milling machining center with high quality for metal work
DRC machining center is suitable for processing machinery and mold manufacturing field of vertical machining center, from the rough machining and finish machining and processing requirements apply, can finish milling, drilling, tapping, boring, and a variety of processes.
Vertical machining center fearturs :
1.High quality resin sand
2. Japanese NSK bearing
3. Twaiwan spindle
4. Germany R+W coupling
5. Taiwan ball screw and locking nut
6. Automatic lubrication system
7. Taiwan pressure cylinder
8. Chip conveyor at optional
|
Machine Type |
MVL1165 |
|
Worktable(length×width ) |
1300X650mm |
|
Maximum load of table |
1000kg |
|
T-slot(number of slot×slot×pitch) |
5-18X120mm |
|
Travel for X/Y/Z axes |
1100/650/650mm |
|
Distance from spindle nose to table surface |
150-800mm |
|
Distance from spindle center to column guide surface |
750mm |
|
CNC system |
FANUC -Oi MF |
|
Rapid shift of axes of X/Y/Z |
24/24/20m/min |
|
Maximum cutting feed speed |
8m/min |
|
Standard tool quantity : Disc 24 |
The larges diamter cutter knife/length : Φ80/300 |
|
Tool exchaing manner : Pneumatic |
Drive manner of spindle : Belt |
|
Average tool exchanging time |
Disc 2.5s |
|
Accuracy of repeated positioning : 0.005mm |
Positioning accuracy : 0.008mm |
|
Spindle speed |
8000r.p.m |
|
Spindle specifications (mode /installation /diamter) |
BT40/150 |
|
Motor power of spindle |
11/15kW |
|
Air pressure flux |
≥0.3 |
|
Integrated weight(kg) |
7500kg |
|
Overall dimension (length×width×height) |
3500x2700x2650mm |
