CK6150 Flat Bed CNC Lathe
|
Model |
CK6150*1000 mm ( GSK980TC3 System) |
|
Processing ability |
Unit ( mm ) |
|
Max. swing over bed |
500 |
|
Max. swing over slide |
250 |
|
Max. Processing length |
1000mm(Optional)1500mm/2000mm |
|
Travel |
|
|
X/Z axis travel |
280/1000mm |
|
Spindle nose |
A2-8 |
|
Spindle |
|
|
Spindle bore diameter |
82mm(Optional)130mm |
|
Spindle inner hole taper |
MT6 |
|
Spindle series |
stepless |
|
Max. spindle speed |
L:70~700,H:160~1800rpm |
|
Chuck size |
Manual chuck K10-250 |
|
Main motor power |
7.5 /11kW |
|
Feed turret |
|
|
X/Z axis torque |
5/15N.m |
|
X/Z axis rapid speed |
6/8 m/min |
|
Turret type |
Electicity |
|
Tool shank size |
25×25 |
|
X/Z axis repeatability |
±0.005 |
|
Tailstock |
|
|
Tailstock diameter |
75 |
|
Tailstock travel |
150 |
|
Tailstock center taper |
MT5 |
|
Others |
|
|
Machine net weight |
3150kg |
|
Machine dimension（L×W×H） |
3750×1700×1820 |
|
Power supply（power/ electric current) |
13kW/20A |
|
Standard configuration |
|
|
Chuck |
250 manual chuck |
|
Tailstock |
Manual tailstock |
|
X axis ball screw |
Domestic（Qishan）FD3210-889-1035 |
|
Z axis ball screw |
Domestic（Qishan）FD2506-407-530 |
|
Electricity turret |
4 position |
|
X、Z axis screw bearing |
Domestic(Derun) |
|
Spindle bearing |
Domestic P5 |
|
Machine casting |
Highquality resin sand casting |
|
Spindle assembly |
Assembly spindle |
|
Oil paint |
Can be customized color |
|
Lubrication |
Domestic |
